General
| Category | Specification |
| Model | MD ULTRA 3.6kW |
| Rated Power | 3600VA / 3600W |
Input
| Category | Specification |
| Voltage | 230 VAC |
| Selectable Voltage Range | 170–280 VAC (For Personal Computers) 90–280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz / 60 Hz (Auto sensing) |
Output
| Category | Specification |
| AC Voltage Regulation (Batt. Mode) | 230 VAC ± 5% |
| Surge Power | 7200VA |
| Efficiency (Peak) | 90% – 93% |
| Transfer Time | 15 ms (For Personal Computers) 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
Battery
| Category | Specification |
| Battery Voltage | 24 VDC |
| Floating Charge Voltage | 27 VDC |
| Overcharge Protection | 33 VDC |
Solar Charger & AC Charger
| Category | Specification |
| Solar Charger Type | MPPT |
| Maximum PV Array Power | 5000W |
| MPP Range @ Operating Voltage | 60 ~ 450 VDC |
| Maximum PV Array Open Circuit Voltage | 500 VDC |
| Maximum Solar Charge Current | 120A |
| Maximum AC Charge Current | 100A |
