Description
| Category | Specification |
| MODEL | PHOTON 3.6KW |
| Rated Power | 3600VA / 3500W |
| INPUT | |
| Voltage | 230 VAC |
| Selectable Voltage Range | 170–280 VAC (For Personal Computers) 90–280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz / 60 Hz (Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 230 VAC ±5% |
| Surge Power | 7000VA |
| Efficiency (Peak) | 90% ~ 93% |
| Transfer Time | 10 ms (For Personal Computers) 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
| No Load Power Consumption | < 70W |
| BATTERY | |
| Battery Voltage | 24 VDC |
| Floating Charge Voltage | 27 VDC |
| Overcharge Protection | 33 VDC |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger Type | MPPT |
| Max. PV Array Open Circuit Voltage | 500 VDC |
| MPP Range @ Operating Voltage | 30 ~ 450 VDC |
| Max. PV Array Power | 5000W |
| Max. Solar Charge Current | 100A |
| Max. AC Charge Current | 80A |
| Max. Charge Current | 100A |
| PHYSICAL | |
| Dimension (DxWxH) (mm) | 358 × 295 × 100 |
| Net Weight (kgs) | 8.2 |
| Communication Interface | RS232 / RS485 |
| ENVIRONMENT | |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
